Processor

Intel Xeon E3-1225 v6 3.3GHz, 8M cache, 4C/4T, turbo (73W)

Memory

4GB (1x4GB) 2400MT/s DDR4 ECC UDIMM

8GB (1x8GB) 2400MT/s DDR4 ECC UDIMM

16GB (1x16GB) 2400MT/s DDR4 ECC UDIMM

Hard Drive

500GB 7.2k RPM SATA 6Gbps Entry 3.5in Cabled Hard Driv

Warranty

3 Year Basic Hardware Warranty Repair, 5X10 HW-Only, 5×10 NBD On-site

Drive Bays

2 x 3.5″ cabled HDD
4 x 3.5″ cabled HDD
4 x 3.5″ hot swap or 2.5″ hot swap in hybrid drive carrier

Dimensions

Depth without bezel: 495.0 mm (19.5 in)
Depth with bezel: 551.3 mm (21.7 in)
Height: 42.8 mm (1.68 in)
Width without rack latches: 434.0 mm (17.08 in)
Width with rack latches: 482.4 mm (18.99 in)

Power

250W cabled PSU

RAID Controllers

S130, H330, H730, H830

Storage

2.5” SATA 7.2K
2.5” nearline SAS 7.2K
2.5” 10K SAS HDDs
2.5” 15K SAS HDDs
2.5” SATA HDDs
3.5” Enterprise SATA 7.2K HDDs
3.5” nearline SAS 7.2K HDDs
3.5” 7.2K SATA entry drives

Slots

2 x PCIe 3.0 slots: x16 slot, full height (1×8 PCIe 3.0)+ x8 slot, low profile (1×4 PCIe 3.0)

Network Controller

Broadcom BCM5720

Communications

2 x 1GbE LOM

Device Access

5 Total USB:
Rear: 2 x USB 3.0 ports
Front: 2 x USB 2.0 ports
Internal: 1 x USB 3.0 por

Embedded Hypervisor (Optional)

Hypervisor Support
Microsoft Windows Server with Hyper-V
VMware vSphereESXi

Rack Support

ReadyRails™ static rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded and 2-post racks.

Warranty

 3-year parts, 3-year labor, 3-year onsite support with next business day response.
